The original image.
And here’s how it will look after adding our light streaks:
The final effect.
Let’s get started!
Step 1: Add A New Blank Layer
We’re going to be adding our light streaks on their own separate
layer, so the first thing we need to do is add a new blank layer to our
document. To do that, click on the
New Layer icon at the bottom of the Layers palette:
Clicking on the “New Layer” icon.
This adds a new blank layer, which Photoshop names “Layer 1″, above our Background layer:
A new layer appears above the Background layer.
Step 2: Select The Pen Tool
As I mentioned at the beginning, we’re going to create our light
streaks by drawing paths and then stroking the paths with a brush. To
draw paths, we need the
Pen Tool, so select it from the Tools palette. You can also press the letter
P to select it with the keyboard shortcut:
Select the Pen Tool.
Step 3: Select The “Paths” Option In The Options Bar
Photoshop gives us three different things that we can do with the Pen
Tool. We can use it to draw vector-based shapes, we can draw paths with
it (which is what we want to do), and we can draw pixel-based shapes.
We select between these three options by clicking on their icons up in
the
Options Bar at the top of the screen. You’ll
see three little square icons grouped together on the left side of the
Options Bar. Click on the icon in the middle, which is the
Paths option:
Click on the “Paths” icons in the Options Bar.
Step 4: Draw A Path Where You Want The First Light Streak To Appear
With the Pen Tool selected and the Paths option chosen in the Options
Bar, we’re ready to draw our first path. I want my light streaks to
appear in the bottom half of the photo, somewhere around the woman’s
shoulders and neck area, so that’s where I’ll draw my first path. You’ll
want to add several curves to your path to make the light streak more
interesting. I’ll start by clicking somewhere in the bottom left corner
of the image to add my first anchor point, then I’ll drag out direction
handles in the direction that I want my path to follow. Again, be sure
to check out our making selection with
pen tool tutorial first if what I just said made no sense to you:
Clicking in the document to add an anchor point, then dragging out direction handles.
I’ll continue drawing the rest of my first path by clicking and
dragging a couple more times with the Pen Tool to add the rest of my
path segments. I now have my first path running from left to right
across the woman’s shoulders and neck area:
The first path has now been added to the image.
Step 5: Select The Brush Tool
Now that we’ve drawn our first path, the next step is to stroke it with a brush. For that, we’ll need Photoshop’s
Brush Tool, so select it from the Tools palette, or simply press the letter
B on your keyboard:
Select the Brush Tool.
Step 6: Select The “40 Sampled Tip” Brush
Photoshop comes with several brushes that would work well for our
light streak effect, but after trying a few of them out, I’ve found one I
like the best. To select it, we’ll need to bring up the Brushes
palette. There’s a few different ways to bring up the Brushes palette,
and one of them is to click on the
Brushes palette toggle icon in the Options Bar at the top of the screen:
Click on the Brushes palette toggle icon to bring up the Brushes palette.
When the Brushes palette appears, click on the words
Brush Tip Shape
in the top left corner of the palette. Then, in the Brush tip selection
area on the right, scroll down near the bottom of the list and select
the
40 Sampled Tip brush. It just says “40″ in
the preview area, but if you have Tool Tips enabled in Photoshop’s
Preferences, you’ll see the words “Sampled Tip” appear when you hover
your mouse over the brush:
Click on the words “Brush Tip Shape” in the top left corner, then click on the “40 Sampled Tip” brush in the selection area.
Step 7: Lower The “Spacing” Amount To 1%
Down at the bottom of the Brushes palette, directly above the brush preview area, you’ll see the
Spacing
option. Whenever you paint with a brush in Photoshop, even though it
usually appears as though you’re painting one continuous stroke, what
Photoshop is really doing is “stamping” the image over and over again
with the brush tip. If the “stamps” are close enough together, they
appear as a continuous stroke.
The Spacing option determines how far apart the
stamps will appear, and by default, the option is set to 30% for our “40
Sampled Tip” brush. That’s too much of a space for our effect. Use the
slider bar to lower the Spacing amount all the way down to 1%.
If you look at the brush preview area after lowering the Spacing amount
to 1%, you’ll see that the brush now appears as one continuous stroke:
Lower the “Spacing” amount to 1% to smooth out the appearance of the brush stroke.
Step 8: Set The Brush Size Control To “Pen Pressure”
If we were to stroke the path with our brush right now, the light
streak effect wouldn’t look very good because the brush would appear at
the exact same size all along the path. We need the brush to taper off
at both ends to create the illusion that the light streak is actually
beginning at one end and ending at the other. For that, we’ll need to
tell Photoshop to simulate pen pressure for us, as if we were drawing
with a pen tablet.
Click directly on the words
Shape Dynamics on
the left of the Brushes palette, directly below “Brush Tip Shape”. Make
sure you click directly on the words, not just in the checkbox to the
left of the words. Clicking inside the checkbox will enable the Shape
Dynamics options but won’t allow us to change any of them. We need to
click on the words themselves to get access to the options. Once you’ve
clicked on the words, you’ll see the Shape Dynamics options appear on
the right of the palette. At the very top, you’ll see the words "Size
Jitter" with a slider bar, and directly below the slider bar is the
Control
option. This is where we get to decide how to control the size of our
brush. We want Photoshop to simulate pen pressure, so select
Pen Pressure from the Control drop-down menu:
Click directly on the words “Shape Dynamics” on the left, then set the “Control” option on the right to “Pen Pressure”.
Now, at the moment, all we’ve done is told Photoshop that we want to
control the size of our brush according to pen pressure, but what if you
don’t actually have a pen tablet? If you don’t have one connected to
your computer, you’ll see a little warning icon appear to the left of
the word "Control" telling you that a pen tablet is required, but don’t
worry about it. In a moment, we’re going to be telling Photoshop to
simulate pen pressure for us, so for this effect, it makes no difference
whether you have a pen tablet or not.
Step 9: Set Your Foreground Color To White
We have our brush ready to go. Now all we need to do is choose the
color we want to paint with. We’re going to want to paint with white,
which means we need our
Foreground color to be white. Press the letter
D
on your keyboard to make sure your Foreground and Background colors are
reset to their defaults, with black as your Foreground color and white
as your Background color. Then press the letter
X to swap them, making white your Foreground color:
The Foreground and Background color swatches in the Tools palette. White is now the Foreground color.
Step 10: Save Your Path
We have our path, we have our brush, and we’ve set our Foreground
color to white. We’re ready to create our first light streak! Switch
over to Photoshop’s
Paths palette, which you’ll
find grouped in with the Layers and Channels palettes. You’ll see your
path listed, which is currently named “Work Path”, along with a preview
of the path on the left, similar to how layers are shown in the Layers
palette with their name on the right and a preview area on the left.
Whenever you create a new path, Photoshop automatically names it “Work
Path”, which means it’s temporary. If you don’t save the path before
drawing a new one, the new path will replace the previous one and you’ll
have lost it. In many cases, this isn’t a problem, but let’s save our
path just in case we want to go back to it later.
To save a path, all we need to do is rename it. Simply
double-click on the name “Work Path” and Photoshop will pop up the
Save Path
dialog box, with the suggested name of “Path 1″ already entered for
you. Click OK to exit out of the dialog box and Photoshop will rename
the path “Path 1″. The path is now saved:
The Paths palette showing the path now saved and renamed “Path 1″.
Step 11: Stroke The Path With The Brush
Let’s create our first light streak. Click on the small,
right-pointing arrow in the top right corner of the Paths palette, which
brings up the Paths palette’s fly-out menu, then select
Stroke Path from the list of options:
Select “Stroke Path” from the fly-out menu.
This brings up the
Stroke Path dialog box. We want to stroke the path with our brush, so make sure the
Tool option is set to
Brush. Then, to tell Photoshop to simulate pen pressure for us, click inside the checkbox to the left of the words
Simulate Pressure:
Set the “Tool” option to “Brush” and make sure “Simulate Pressure” is selected.
Click OK to exit out of the dialog box and Photoshop will stroke the
path with the brush, creating our first light streak. Notice how the
brush stroke tapers off at both ends thanks to that “Simulate Pressure”
option:
The image after stroking the path with the brush.
If you think your brush stroke is either too thick or too narrow, simply press
Ctrl-Z (Win) /
Command-Z (Mac) to undo the stroke, then make your brush larger or smaller by pressing either the
left or right bracket keys
on your keyboard. The left bracket key makes the brush smaller, and the
right bracket key makes it larger. Try again once you’ve resized your
brush.
We’ve added our first light streak, but it doesn’t look much like a
light streak at the moment. It looks like a fancy white brush stroke,
which is exactly what it is. To make it look more like a light streak,
we need to add some color and some glow effects, and for that, we’ll use
a couple of simple
layer styles.
Step 12: Add An “Outer Glow” Layer Style
Switch back over to your Layers palette. You’ll see your white brush stroke in the preview area of "Layer 1". Click on the
Layer Styles icon at the bottom of the Layers palette and select
Outer Glow from the list of layer styles that appears:
Add an “Outer Glow” layer style in the Layers palette.
This brings up Photoshop’s
Layer Style dialog box set to the Outer Glow options in the middle column. Change the
Blend Mode option at the top to
Linear Light,
which will give us a much more intense glow than what we’d normally
get. Then choose a color for your glow by clicking on the small
color swatch directly below the word “Noise”. This will bring up Photoshop’s
Color Picker.
You can either choose your color from the Color Picker, or if you
prefer, you can sample a color directly from the image. To sample a
color, simply move your mouse cursor over the image. You’ll see your
mouse icon turn into the
Eyedropper icon. Move
the eyedropper over the color you want to sample, then click to sample
it. I’m going to sample a light area of the woman’s skin to use as my
outer glow color:
Sampling a color from the image to use as the color for the outer glow.
Once you’ve chosen your color, click OK to exit out of the Color Picker. Lastly, increase the
Size of the outer glow to somewhere around
30 pixels. You may need to raise or lower that amount depending on the size and resolution of your image:
Change the blend mode, color and size of the outer glow.
Don’t exit out of the Layer Style dialog box just yet because we
still have one more layer style to add. Here’s how my light streak looks
so far after adding my outer glow:
The image after applying an outer glow to the light streak.
Step 13: Add An “Inner Glow” Layer Style
We’ve added an outer glow layer style to our light streak. Now let’s
add an inner glow style. With the Layer Style dialog box still open,
click on the words
Inner Glow on the left of the dialog box, directly below “Outer Glow”:
Select “Inner Glow” on the left of the Layer Style dialog box.
You’ll see the
Inner Glow options appear in the middle column of the dialog box. Once again change the
Blend Mode option at the top to
Linear Light. Then click on the
color swatch
below the word “Noise” and either choose a color from the Color Picker
or, as I did with the outer glow, sample a color directly from the
image. I’m going to sample a darker area of the woman’s skin for my
inner glow color:
Sampling a darker skin color to use as the color for the inner glow.
Once you’ve chosen the color for your inner glow, click OK to exit out of the Color Picker. Finally, increase the
Size of your inner glow to around
10 pixels. As with the outer glow, you may need to play around with this value a bit depending on the size and resolution of your image:
Change the blend mode, color and size of the inner glow.
Click OK when you’re done to exit out of the Layer Style dialog box. Your light streak should now have an intense glow to it:
The light streak now appears with a bright, colorful glow.
That thin dark line we’re seeing through the middle of our light
streak is the path. Don’t worry, it won’t be there when we’re done.
Step 14: Edit The Path To Create A Slight Variation Of It
Let’s make our light streak a bit more interesting by adding a couple
more streaks to it. We can do that easily by simply editing our path to
create some slight variations of it and then stroking each variation
with our brush. Switch back to your Paths palette so we can edit our
path. Then, hold down your
Ctrl (Win) /
Command
(Mac) key and move your mouse cursor directly over any part of the
path. As soon as it’s over the path, you’ll see the cursor turn into a
white pointer, which means you now have temporary access to Photoshop’s
Direct Selection Tool, which is the tool we need to edit our path:
Hold down “Ctrl” (Win) / “Command” (Mac) and
move the mouse cursor directly over the path to temporarily access the
Direct Selection Tool (white pointer).
Click on the path with the Direct Selection Tool to select it, then
make some minor adjustments to the path to create a slightly different
path. You can drag an anchor point to a slightly different spot, or move
direction handles to adjust the curves of the path, or even drag a path
segment to a slightly different position. Just don’t touch the anchor
points at either end of the path because we want each variation we
create to begin and end at the exact same spot. So other than those two
anchor points, the rest of the path can be edited any way you like.
We’re not looking for major changes to the path. Small, subtle changes
are all we need.
Here, I’ve changed the two main curves of my path
slightly by dragging the two direction handles extending out from my
middle anchor point. You can see how the curves of the path no longer
exactly match the curve of the first light streak:
Create a slight variation of the initial path by moving anchor points, direction handles or path segments.
We can now stroke this variation of the path with our brush. But
before we do, we’ll probably want to use a slightly smaller brush this
time, so press the
left bracket key on your keyboard a couple of times to make the brush a bit smaller.
To stroke the variation of our path, there’s no need to go through
the hassle of selecting “Stroke Path” from the Paths palette’s fly-out
menu like we did last time. Simply click on the
Stroke Path icon at the bottom of the Paths palette:
Click on the “Stroke Path” icon at the bottom of the Paths palette.
Photoshop strokes the new path we created with our brush. Since we’re
still working on the same layer in the Layers palette, the Outer Glow
and Inner Glow layer styles are automatically applied to our new light
streak:
The new path has now been stroked with the brush, and the layer styles are automatically applied to it.
Step 15: Create A Couple More Path Variations And Stroke Them With The Brush
Repeat the previous step one or two more times to create more
variations of the path and stroke each one with the brush. Try changing
the size of the brush each time using the
left and right bracket keys to add even more interest to the light streak. If you don’t like the brush stroke you just added, simply press
Ctrl+Z (Win) /
Command+Z (Mac) to undo it, then re-edit the path and try again.
If you want to see what your light streak looks like without the path
blocking your view, simply click anywhere in the empty area below the
path in the Paths palette. This will deselect the path and hide it from
view. To see the path again, click on it in the Paths palette. You’ll
need to have your path visible any time you want to stroke it with your
brush. If the path is not visible, the icons at the bottom of the Paths
palette become grayed out and unavailable.
Here’s my image after editing my path a couple
more times and stroking each new path variation with the brush. Again,
since we’re still working on the same layer, “Layer 1″, in the Layers
palette, the Outer Glow and Inner Glow layer styles are automatically
applied to each new brush stroke. I’ve hidden my path from view so we
can see more easily what the light streak now looks like with all its
different variations:
The first light streak after adding a few variations to it.
Step 16: Copy The Layer Styles On “Layer 1″
And with that, we’ve created our first light streak! You’re probably
going to want to add at least one more to your photo, and it’s a good
idea to place each light streak on its own layer, but we can cut down on
some of the work we’ll need to do by copying the layer styles we’ve
already applied to our first light streak and simply pasting them onto
each new layer we create. Switch back over to your Layers palette. You
should still have “Layer 1″ selected. Go up to the
Layer menu at the top of the screen, choose
Layer Style, and then choose
Copy Layer Style:
With “Layer 1″ selected, go to Layer > Layer Style > Copy Layer Style.
Step 17: Add A New Blank Layer
Click on the
New Layer icon at the bottom of
the Layers palette to add another blank layer. Photoshop will add the
new layer above “Layer 1″ and automatically name it “Layer 2″:
Add a new blank layer above “Layer 1″.
Step 18: Paste The Layer Styles Onto The New Layer
With the new layer selected, go back up to the
Layer menu at the top of the screen, choose
Layer Style once again, and this time, choose
Paste Layer Style:
Go to Layer > Layer Style > Paste Layer Style.
The Outer Glow and Inner Glow styles from “Layer 1″ are now added to
“Layer 2″ and will automatically be applied to the next light streak we
create!
Step 19: Add Another Light Streak
With a new layer added and the layer styles from “Layer 1″ already
applied to the new layer, we can easily create a second light streak.
Simply draw a new path with the Pen Tool, save the path if you want by
renaming it “Path 2″ (or whatever you want to name it), then stroke the
path with the brush. Once you’ve created the main light streak, hold
down
Ctrl (Win) /
Command
(Mac) to access the Direct Selection Tool and edit the path, moving
anchor points, direction handles and/or path segments to create a few
slight variations of it, and then stroke each variation with the brush,
using a different brush size each time.
Here’s my result after adding a second light streak to my photo:
The image after adding a second light streak.
If you don’t want both light streaks to be the same color, you can
easily change the colors simply by editing the layer styles. Let’s say I
want my second light streak to be a different color. To edit the layer
styles, all I need to do is
double-click on the Layer Style icon on the far right of “Layer 2″:
Double-click on the Layer Style icon to edit the layer styles for that layer.
This will pop open the Layer Style dialog box for me. All I’d need to do is click on the words
Outer Glow
on the left side of the dialog box, which brings up the Outer Glow
options in the middle column, then click on the color swatch and choose a
new color either from the Color Picker or by sampling a different color
from the image. Click OK to exit out of the Color Picker, then click on
the words
Inner Glow on the left to access the
Inner Glow options. Click the color swatch, choose a new color, click OK
to exit out of the Color Picker, then click OK to exit out of the Layer
Style dialog box. You can edit the colors of the light streaks any time
you want simply by editing the layer styles.
Here’s my final result after editing the layer styles on “Layer 2″
and changing the color of my second light streak slightly, using colors I
sampled from the woman’s hair:
The final result.
